16. MAINTENANCE
The following items should be checked occasionally for tightness;
or if they have been loosened for maintenance service.
Wheel Nut Torque Specifications
Bolt Size Specification
Front M10X1.25 20Ft.Lbs 27N.m
Rear M12X1.25 50Ft.Lbs 69N.m
NOTE: All nuts that have a cotter pin installed must be
serviced by an authorized Dealer.
Front Wheel Hub Tightening
Front wheel bearing tightness and spindle nut retention are
critical component operations. Service work must be performed
by an authorized dealer.
Front Rear
Flange nuts: install with Tapered nuts: install with
Flat side against wheel tapered side against wheel
82
