7.CONTROL AND PARTS FUNCTIONS
Oil System
The oil tank is located on the right side of the engine .
To check the oil:
1. Set machine on a level surface.
2. Start the engine and let it idle
for 20-30 seconds.
3. Stop the engine, remove
dipstick (1)and wipe dry with
a clean cloth.
4.Put dipstick into the oil tank (don’t screw in it), remove it and
read the oil level.
5.Remove dipstick and check to see that the oil level is between
the full and add marks(2). Add oil as indicated by the level on the
dipstick. Do not overfill.
CAUTION
Use only SAE 15W/40, SG OIL. Never substitute or mix oil
brands. Serious engine damage and voiding of warranty can
result.
43
