Vm PT Ratio [/1]
Mains potential transformers ratio.
Step: 0,1 V / V
Range: 0,1 – 500,0 V / V
Nomin Volts [V]
Nominal generator voltage (phase to neutral)
Step: 1V
Range: 80 – 20000 V
Nominal Freq [Hz]
Nominal generator frequency (usually 50 or 60 Hz )
Step: 1Hz
Range: 45 – 65 Hz
ActivityAtOFF [ENABLE/DISABLE]
ENABLE: Controller at OFF mode stays at standard behavior of OFF mode.
DISABLE: Controller at OFF mode opens all binary outputs and there is Fault reset active all the
time.
ControllerMode [OFF, MAN, AUT,TEST]
Equivalent to Controller mode changes by MODE→ or ←MODE buttons.
NOTE:
Controller Mode change can be separately password protected.
ControllerAddr (1 .. 32) [-]
Controller identification number. It is possible to set controller address different from the default value
(1) so that more controllers can be interconnected (via RS485) and accessed e.g. from Modbus
terminal.
NOTE:
When opening connection to the controller it's address has to correspond with the setting in PC tool.
From LiteEdit it is only possible to connect to controllers with address 1.
COM1 Mode [DIRECT/MODEM/MODBUS]
Communication protocol switch for the COM1 channel.
DIRECT: LiteEdit communication protocol via direct cable.
MODEM: LiteEdit communication protocol via modem.
MODBUS: Modbus protocol. See detailed description in InteliCommunication guide.
NOTE:
For details on communic. speed and other technical parameters please see chapter Technical Data.
For detail description see chapter Modbus protocol. Register oriented modbus is supported.
COM2 Mode [DIRECT/MODBUS]
Communication protocol switch for the COM2 channel, if dual communication module is pluged in.
DIRECT: LiteEdit communication protocol via direct cable.
MODBUS: Modbus protocol. See detailed description in InteliCommunication guide.
NOTE:
For details on communic. speed and other technical parameters please see chapter Technical Data.
For detail description see chapter Modbus protocol. Register oriented modbus is supported.
