Communication object vs. Register
All the data intended for communication has its representation as communication objects in the
controller. The communication object is represented by the n-byte array in the controller memory and
identified by the unique 16-bit communication object number. The register, according to Modbus
communication protocol, represents a two-byte data and in communication functions is referenced by
16-bit register address. Further in the description of communication functions the communication
object number will always be used as a register address and length of the communication object
will be expressed by number of registers. Just one communication object can be read or written
by one communication function.
NOTE:
To obtain communication object numbers it is possible to download the actual controller description
on-line from controller or from (ail) archive and use “export data” function from LiteEdit software.
Communication object list (exported from default IA-NT-PWR archive)
Setpoints of IA-NT PWR:
Name Firmware ver. Application Date App. ver. Ser. num. Filename
IA-NT-PWR
IA-NT-1.2.3
R:7.01.2010
PWR 8.1.201 1,2 12345678
IA-NT-PWR-
1.2.AIL
Group Name Value Dimens. Password Com. obj. Lo limit Hi limit Data type
Basic Settings ControllerName PWR No 8637 Short string
Basic Settings Nominal Power 200 kW No 8276 1 5000 Unsigned 16
Basic Settings Nomin Current 350 A No 8275 1 10000 Unsigned 16
Basic Settings CT Ratio 2000 /5A No 8274 1 5000 Unsigned 16
Basic Settings PT Ratio 1,0 /1 No 9579 0,1 500,0 Unsigned 16
Basic Settings Vm PT Ratio 1,0 /1 No 9580 0,1 500,0 Unsigned 16
Basic Settings Nominal Volts 231 V No 8277 80 20000 Unsigned 16
Basic Settings Nominal Freq 50 Hz No 8278 45 65 Unsigned 16
Basic Settings ActivityAtOFF ENABLED No 11620 String list
Basic Settings ControllerMode OFF No 8315 String list
Basic Settings ControllerAddr 1 Yes 24537 1 32 Unsigned 8
Basic Settings COM1 Mode DIRECT Yes 24522 String list
Basic Settings COM2 Mode DIRECT Yes 24451 String list
Basic Settings GenStart Logic CLOSE-ON No 9100 String list
Basic Settings Batt Undervolt 18,0 V No 8387 8,0 40,0 Integer 16
Basic Settings Batt Overvolt 36,0 V No 9587 18,0 40,0 Integer 16
Basic Settings Batt Volt Del 5 s No 8383 0 600 Unsigned 16
Engine Params Prestart Time 0 s No 8394 0 600 Unsigned 16
Engine Params Cooling Time 0 s No 8258 0 3600 Unsigned 16
Engine Params Max Star tDel 20 s No 10914 0 601 Unsigned 16
Engine Params Min Stab Time 3 s No 8259 1 300 Unsigned 16
Engine Params Stop Time 60 s No 9815 1 3601 Unsigned 16
Gener Protect GenerProtect ENABLED No 11030 String list
Gener Protect Short Crct Trp 250 % No 8282 100 500 Unsigned 16
Gener Protect Short Crct Del 0,00 s No 9991 0,00 10,00 Unsigned 16
Gener Protect Amps IDMT Del 4,0 s No 8283 1,0 60,0 Unsigned 16
Gener Protect Amps Unbal Trp 50 % No 8284 1 200 Unsigned 16
Gener Protect Amps Unbal Del 5,0 s No 8285 0,0 600,0 Unsigned 16
Gener Protect Gen >V Trp 110 % No 8291 70 200 Unsigned 16
Gener Protect Gen <V Trp 70 % No 8293 0 110 Unsigned 16
Gener Protect Gen V Del 3,0 s No 8292 0,0 600,0 Unsigned 16
Gener Protect Volt Unbal Trp 10 % No 8288 1 200 Unsigned 16
Gener Protect Volt Unbal Del 3,0 s No 8289 0,0 600,0 Unsigned 16
Gener Protect Gen >Freq Trp 110,0 % No 8296 85,0 200,0 Unsigned 16
Gener Protect Gen <Freq Trp 85,0 % No 8298 0,0 110,0 Unsigned 16
Gener Protect Gen Freq Del 3,0 s No 8297 0,0 600,0 Unsigned 16
AMF Settings RetFromIsland AUTO No 9590 String list
