IGS-NT Communication Guide
140
Number of register of particular protection you can get as exporting of modbus registers list from GenConfig.
Open an archive in GenConfig (ver. 2.5 and higher), open File menu and choose “Generate Cfg Image -->
Modbus registers all” (see “How get numbers of ModBus communication objects” chapter). Open the list of
modbus registers you have got and see registers with number according the table. Here you can see meaning of
particular modbus registers. Each register carries informations about two protections (Protection#1 and
Protection#2).
Register Protection#2 Protection#1
45754 Warning 7 Warning 8
45755 Warning 9 Warning 10
45756 SD 11 SD 12
45863 Oil press Water temp
45864 Fuel level N/A
45925 BIN 1 BIN 2
45926 BIN 3 BIN 4
Meaning of register content
Register map
Bit 0-7 ................. Protection #1
Bit 8-15 ............... Protection #2
Bit 0-2 ................. Protection #1 Level 1
Value Meaning
0 Level 1 inactive
2 Level 1 active, confirmed
3 Level 1 active, blocked
4 Level 1 previously active, not confirmed yet
6 Level 1 active, not confirmed yet
7 Level 1 active, not confirmed yet, blocked
Bit 3-5 ................. Protection #1 Level 2
Value Meaning
0 Level 2 inactive
2 Level 2 active, confirmed
3 Level 2 active, blocked
4 Level 2 previously active, not confirmed yet
6 Level 2 active, not confirmed yet
7 Level 2 active, not confirmed yet, blocked
