Loading System MkII Assembly
33
Make sure that the Lock Pin is properly installed, latch is dropped
and that it is secured with the wire. Under no circumstances shall a
substitute Lock Pin other than ones provided by Combisafe be
used.
10.2 Connect the Fall Arrest Block. Make sure that the component is correctly
attached and secured to the SkyReach Anchor point. Figure 29 shows
how the 6,2 m Falcon Fall Arrest Block is attached to the anchor point.
Figure 29. Attaching the 6,2m Fall Arrest Block.
It is strongly recommended that a retrieving rope is tied to the Fall
Arrest Block karabiner to enable the operative to pull the cable out
and allow simple connection to the operative’s 0.3 m harness
extender. It is not recommended to leave the cable of the block
pulled out in this matter, due to possible damage to the unit.
