4. Expansion Audio Monitor (EX-700A)
4.1. EX-700A Identification
1. Speaker
2. In use LED
3. Monitor LED
4. Intercom LED
5.
6. Microphone
7. Cut-off button( )
8. Intercom button( )
9. Monitoring button( )
10. Door release button( )
11. Power switch
12. Bell Volume tuner( )
13. Speaker Volume tuner( )
14.
Communication LED
JP2, door status report option
Bell tone indication (JP2 left) (default)
LED light on Door Open Button (JP2 right)
7
1
7 8 9 106
2
3
5
4
11
12
13
178mm
(7.0)
36mm
(1.42)
118mm
(4.65)
[EX-700A]
14
