Comelit HFX-700M KIT - Optional Video Input Converter (EX-VIN) Installation; Install Video Input Converters; EX-VIN Wiring and Setting

25
PT1
PT2
DG1
DG2
OUT+
OUT-
DR2
DR1
POWER
<+>
<->
Main monitor
wiring terminal
Red
Black
1
EX-VIN wiring terminal
1
2
3
CCD camera
2
3
8. Optional video input converter (EX-VIN) Installation
8.1. Install video input converter
A. Package contains no accessories.
B. Wire EX-VIN to the video distribution box of the camera
C. Plug in BNC, no setting is necessary
8.2. EX-VIN wiring and setting
2-wire terminals on EX-VIN
DR1 or DR2 terminals on main monitor
BNC for camera video
