Comelit HFX-700M KIT - 3.3. Install Door Camera; 4. EX-700 H Installation

EX-700H or EX-700A
HFX-700M EX-700D
POWER LED
POWER
IN
OUT1
OUT2
OUT3
OUT4
EX-HUB
EX-700H or EX-700A
EX-700H or EX-700A
NOTE 1:OUT4 can also be
used to connect to a expansion
monitor.
NOTE 2:wiring distance<300ft.
C Max
POWER LED
POWER
IN
OUT1
OUT2
OUT3
OUT4
EX-HUB
C Max
A Max
A Max
B Max
C Max
12
