Comet CBM Series Instructions For Assembly, Operation And Maintenance

31
SPECIFICATIONS AND TECHNICAL DATA
Wheelbarrows consist of a tubular steel frame, a polyethylene tank, rubber tubing, a spray lance and a
CBM module (containing a battery-operated EVERFLO motor pump). They can be equipped with a hose
reel (optional).
In the following table, where required, reference is made to the EVERFLO motor pump that is included
on the machine.
CRRC 51 ECO CRRC 81 ECO CRRC 120 ECO
CBM 1200 HP CBM 1500 HP CBM 1200 HP CBM 1500 HP CBM 1200 HP CBM 1500 HP
ELECTRICAL CONNECTION
Voltage V
12
Assorbimento A 6,5 10,5 6,5 10,5 6,5 10,5
Motor pump protection fuse A 10 15 10 15 10 15
System protection fuse A 15
HYDRAULIC CONNECTION
Maximum water supply temperature °C [°F] 40 [104]
Minimum water supply temperature °C [°F] 5 [41]
Minimum water supply ow rate
L/min
[US gpm]
6,4
[1,7]
8,0
[2,2]
6,4
[1,7]
8,0
[2,2]
6,4
[1,7]
8,0
[2,2]
Maximum water supply pressure bar [PSI] 1,0 [15]
Maximum priming depth m [ft] 2,5 [8,0]
PERFORMANCE
Maximum ow rate
L/min
[US gpm]
4,2
[1,1]
5,7
[1,5]
4,2
[1,1]
5,7
[1,5]
4,2
[1,1]
5,7
[1,5]
Maximum pressure bar [PSI] 6,9 (100] 10,3 (150] 6,9 (100] 10,3 (150] 6,9 (100] 10,3 (150]
Maximum sound pressure level dB(A) 73
Uncertainty dB(A) 0,8
MAXIMUM MASS
Weight without battery kg [lb] 22 [48,5] 28 [61,7] 30 [66,1]
BATTERY
Deep-cycle dry cell battery V - Ah 12 - 24 12 - 35 12 - 24 12 - 35 12 - 24 12 - 35
BATTERY CHARGER
Battery charger kit with cables
(supplied with CBM module)
V - Ah 12 - 4
COMPONENT IDENTIFICATION
Refer to Figs. 1 to 8 at the beginning of the manual.
1.
Delivery hose
16.
Filling lter
2.
Cap
17.
Lance tting
3.
By-pass hose tting
18.
Sprayer lance trigger
4.
By-pass hose
19.
Head with nozzle
5.
Suction lter
20.
Pressure adjustment knob
6.
Wheelbarrow identication label
21.
Pressure gauge
7.
Handles
22.
Delivery tting
8.
Suction hose
23.
By-pass tting
9.
Base
24.
Filter knob with valve
10.
Tank drain cap
25.
Suction lter ring nut
11.
Warning label
26.
Sleeve with chemical product in use information
12.
Sprayer lance
27.
Pressure control valve
13.
Frame
28.
CBM module
14.
Tank
29.
Machine’s technical data CE plate
15.
Suction tting
EN
