CommScope CAP MX Series User Manual

M0201ANC_uc CommScope Era
™
Fiber Low Power Carrier Access Point Installation Guide
© June 2019 CommScope, Inc. Page 25
Mount the Fiber CAP L
Mounting a CAP L with a Flat Mounting Bracket Kit
Figure 6 shows the Flat Mounting Bracket Kit (CommScope PN 7774353-xx), which provides the mounting
brackets required to mount a Fiber CAP L to a wall or other flat surface.
Six M6-1.0 x 14 mm screws
Two Mounng Brackets
Figure 6. Flat Mounting Bracket Kit (PN 7774353-xx)

CommScope CAP MX Series Specifications

General

Brand	CommScope
Model	CAP MX Series
Category	Wireless Access Point
Language	English
