M0201ANC_uc CommScope Era

™

Fiber Low Power Carrier Access Point Installation Guide

Mount the Fiber CAP L

7 Insert an M8x16 screw in the top screw hole on the left Mounting Adapter attached to CAP L-1, and then

insert screw three or four turns.

M8x16 screw

Mounng

Adapter

Mounng

Adapter

8 Repeat Step 7 for the right Mounting Adapter.
