compact electric CDMRE 100 Manual Page 3
1230 Vienna, Großmarktstraße 22
PHONE: + 43 / 1 / 815-12-71-0 or + 43 / 1 / 815-51-74-0
FAX: + 43 / 1 / 813-64-21-21
Homepage: http://www.compactelectric.at
1. GENERAL INFORMATION
1.1. Safety instructions
CDMRE-100 is a voltage and frequency monitoring relay for mains and system protection (GS protec-
tion). It is intended for disconnecting the feeding generators and systems (e.g.: heating power, wind
power, hydroelectric power and photovoltaic systems) in case of impermissible voltage and frequency
values, mains-side faults or power failures from the public supply mains using a coupling switch.
CDMRE-100 is equipped with a separate auxiliary voltage input.
Only expert electricians may install and commission the device. An expert electrician can identify and
avoid possible dangers independently on the basis of his/her technical training, knowledge and expe-
rience. The expert electrician is specially trained for the working environment in which he/she works
and knows the relevant standards and regulations.
CDMRE-100 is built according to the latest technological advancements and the recognized safety reg-
ulations. Nevertheless, improper use may result in danger for the user, third parties or devices and
material assets.
In order to maintain the functional safety of the GS protection, the feedback contacts of the two con-
tactors must be monitored by CDMRE-100 (see wiring example on page 25). The feedback contacts can
be designed as NC contacts as well as NO contacts. The respective version can be parameterized in the
"General 1" menu of CDMRE-100.
Danger to life due to electric current!
If live parts are touched, there is an immediate danger to life due to the electric current. Only expert
electricians may carry out work on electrical systems as well as any activities related to installation,
commissioning as well as those during the operation of the device.
Use this device only:
- for the intended purposes
- in a technically safe condition
- in compliance with the accident prevention rules and regulations applicable at the place
of use
Immediately rectify all faults that could affect safety.
Do not make any unauthorized modifications and use only spare parts and accessories sold or
recommended by the manufacturer of the devices.
In case of obvious damage, do not continue to use the device.
If the device has been subjected to overvoltage or short-circuit current, check it and replace it
if necessary.
This manual has been prepared with the utmost care. However, errors and mistakes cannot be com-
pletely ruled out. Compact Electric does not assume any liability for personal injuries or damage to
property resulting from errors or mistakes in this manual.
Always keep this user manual in the immediate vicinity of the device.
