1.4. Front view and connection allocation
Figure 2 - front view
1. RS232/serial interface
2. Connection allocation, see figure 3
3. Escape key
4. Up key
5. Down key
6. Enter key
Figure 3 - connection allocation
1
3
4
5
6
2
2
