Removal and Replacement Procedures 5-9
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: The Integrity Group Saved by: The Integrity Group Saved date: 10/26/00 12:36 PM
Part Number: 128679-006 File name: Ch05
Removing the Keyboard
1. Prepare the computer for disassembly (Section 5.3).
2. Turn the computer bottom side up with the front facing forward.
3.
Remove the screw that secures the keyboard (Figure 5-7).
Figure 5-7. Removing the Keyboard Screw
