Removal and Replacement Procedures 5-31
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: The Integrity Group Saved by: The Integrity Group Saved date: 10/26/00 12:36 PM
Part Number: 128679-006 File name: Ch05
System Board
continued
Armada V300 only
Intel Celeron 500-MHz processor with 64 MB
SDRAM; used only with config. codes
beginning with DVR.
177748-001
Intel Celeron 466-MHz processor with 64 MB
SDRAM; used only with config. codes
beginning with DVP.
177747-001
Intel Celeron 466-MHz processor with 64 MB
SDRAM; used only with config. codes
beginning with:
160535-001
CXX DJD3 DJD4 DVQ
Intel Celeron 400-MHz processor with 64 MB
SDRAM; used only with config. codes
beginning with:
160534-001
CXW DJD1 DJD2
Intel Celeron 400-MHz processor with 32 MB
SDRAM; used only with config. codes
beginning with CXV.
159540-001
Removing the System Board
1. Prepare the computer for disassembly (Section 5.3) and, in the
order below, remove the following components:
■
Modem or modem/Network Interface Card (Section 5.5)
■
Touch button (Section 5.6)
■
Keyboard (Section 5.7)
■
Display assembly (Section 5.9)
■
LED board (Section 5.11)
■
Top cover (Section 5.12)
■
Front shield (Section 5.13)
■
Diskette drive (Section 5.14, Armada V300 only)
To Next Page
