Compaq Armada E500 Series Maintenance And Service Guide

Connector Pin Assignments A-5
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: David Calvert Saved by: The Integrity Group Saved date: 09/13/00 2:38 PM
Part Number: 128679-005 File name: Appa.doc
Table A-7 continued
Pin Signal Pin Signal
57 INIT LD6 91 PS2 VCC
58 SLCTIN LD7 92 SERIRQ
59 GND 93 PS2 CLK
60 PDATA0 LD8 94 EXPREQ
61 PDATA1 LD9 95 AD[29]
62 PDATA2 LD10 96 AD[31]
63 PDATA3 LD11 97 AD[30]
64 GND 98 AD[28]
65 PDATA4 LD12 99 AD[26]
66 PDATA5 LD13 100 GND
67 PDATA6 LD14 101 AD[24]
68 PDATA7 LD15 102 AD[22]
69 GND 103 AD[20]
70 ERROR LCLK 104 AD[18]
71 RXD1 LVREQ 105 AD[16]
72 TXD1 LCREQ 106 GND
73 RTS1 LEN 107 AD[15]
74 GND 108 AD[13]
75 CTS1 LIIC CLK 109 AD[11]
76 DTR1 LIIC DAT 110 AD[09]
77 DSR1 EX 111 GND
78 DCD1 EX 112 AD[06]
79 12C DATA 113 AD[04]
80 GND 114 AD[02]
81 12C CLK 115 AD[00]
82 GND 116 GND
83 HDSEL 117 FRAME
84 GND 118 TRDY
85 WPROT 119 STOP
86 EBOXS2 /GND 120 PAR
87 ERDY 121 CBE0
88 EBOXL /GND 122 CBE1
89 FLUSHREQ 123 GND
90 MEMACK 124 KB CLK
Continued

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
