Compaq Armada E500 Series Maintenance And Service Guide

A-6 Connector Pin Assignments
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: David Calvert Saved by: The Integrity Group Saved date: 09/13/00 2:38 PM
Part Number: 128679-005 File name: Appa.doc
Table A-7 continued
Pin Signal Pin Signal
125 RSVD1/M CTRL2 151 AD[12]
126 XSC/L OUT SN 152 AD[10]
127 RSVD2/M OFF HOOK 153 AD[08]
128 KB DATA 154 GND
129 MGND 155 AD[07]
130 STANDBY 156 AD[05]
131 M DRZP 157 AD[03]
132 M DRXN 158 AD[01]
133 VBATT 159 GND
134 EXPGNT 160 CBE3
135 VBATT 161 CBE2
136 GND 162 IRDY
137 VBATT 163 DEVSEL
138 PS2 DATA 164 LOCK
139 VBATT 165 OERR
140 AD[25] 166 SERR
141 VBATT 167 GND
142 AD[27] 168 RSVD3
143 VBATT 169 M 12C CLK
144 AD[23] 170 M 12C DATA
145 GND 171 M RING
146 AD[21] 172 MGND
147 AD[19] 173 M DXTN
148 AD[17] 174 GND
149 GND 175 M DXTP
150 AD[14] 176 MSTRBAT

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
