Product Description 1-27
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: The Integrity Group Saved by: The Integrity Group Saved date: 10/26/00 12:32 PM
Part Number: 128679-006 File name: Ch01
Table 1-9
Keyboard Components (continued)
Item Component Function
1 Hard drive light (green) Turns on when the hard drive is being
accessed.
2 MultiBay light (green) Turns on when a MultiBay device is being
accessed or a battery pack in the MultiBay
is charging or waiting to be charged.
3 Num lock light Turns on when the numeric lock function is
on.
4 Caps lock light Turns on when the caps lock function is on.
5 Scroll lock light Turns on when the scroll function is on.
6 Display switch Turns off the display if it is closed while the
computer is turned on.
7 Page up and page
down keys
Move to the previous or next screen.
8 Embedded numeric
keypad
Converts keys to numeric keypad.
9 Cursor-control keys Move the cursor around the screen.
10 Windows application
key
Displays shortcut menu for item beneath
mouse cursor.
11 TouchPad (TouchPad
models only)
Moves the mouse cursor, selects, and
activates.
12 Left and right
TouchPad buttons
(TouchPad models
only)
Function like the left and right mouse
buttons on an external mouse.
13 Microsoft logo key Displays the Windows Start menu.
14 Caps lock key Turns on the caps lock function.
