Illustrated Parts Catalog 3-3
Table 3-1
Spare Parts: Computer System Major Components
Item Description Spare Part Number
1 Display assembly
14.1-inch, XGA, CTFT
13.3-inch, XGA, CTFT
135219-001
135218-001
2 Touch button with TouchPad 173721-001
3 Touch button 135226-001
4 Top cover
includes LED board and Internet buttons; used with the
following SKUs:
192999-001
470011-XXX
206645-XXX
215198-XXX
206646-XXX
215199-XXX
206647-XXX
includes LED board; used with the following SKUs: 176468-001
205857-XXX
205860-XXX
215197-XXX
205858-XXX
205862-XXX
205861-XXX
205859-XXX
215191-XXX
does not include LED board; used with the following SKUs: 135224-001
124898-XXX
124939-XXX
139114-XXX
139120-XXX
164462-XXX
400324-XXX
400327-XXX
400330-XXX
400333-XXX
124899-XXX
124940-XXX
139116-XXX
140141-XXX
400322-XXX
400325-XXX
400328-XXX
400331-XXX
124938-XXX
124941-XXX
139117-XXX
140142-XXX
400323-XXX
400326-XXX
400329-XXX
400332-XXX
Plastics Kit, includes: 135230-001
5a
5b
Switch cover (2)
Modem cover
not illustrated:
mini PCI dummy card
display screw covers (4)
infrared lens
power switch
left & right display covers
computer feet (4)
PC Card dummy cards (2)
RJ-11 & RJ-45 covers
6 Keyboard - TouchPad model 125788-XX1
Belgian
Brazilian
Danish
French
Canadian
French
German
International
-181
-201
-081
-121
-051
-041
-021
Italian
Japanese
Korean
Latin American
Spanish
Norwegian
Portuguese
-061
-291
-AD1
-161
-091
-131
Spanish
Swedish
Swiss
Taiwanese
U.K. English
U.S. English
-071
-101
-111
-AB1
-031
-001
Keyboard - EasyPoint IV model 125788-XX2
Arabic
Belgian
Brazilian
Danish
French
Canadian
French
German
-172
-182
-202
-082
-122
-052
-042
International
Italian
Japanese
Korean
Latin American
Spanish
Norwegian
Portuguese
-022
-062
-292
-AD2
-162
-092
-132
Spanish
Swedish
Swiss
Taiwanese
Turkish
U.K. English
U.S. English
-072
-102
-112
-AB2
-142
-032
-002
7 USB board assembly (includes mouse connector and video
connector)
135229-001
