Removal and Replacement Procedures 5-7
Inserting a Primary Battery Pack in the Battery Bay
CAUTION: To prevent damage to the computer, do not insert a battery pack until the
computer is fully reassembled.
1. Close the computer.
2. Tilt the computer up ➊ (Figure 5-6).
3. With the smooth side of the battery pack facing up and the battery cells facing in,
lead the rounded edge of the battery pack into the battery bay. Angle the battery
pack into the bay until it is fully seated ➋.
Figure 5-6. Inserting a Battery Pack
4. If the computer is in Suspend, press the suspend button to return to your work.
Refer to Section 5.8 for information on removing a MultiBay battery pack.
