Compaq Armada M700 Series

Removal and Replacement Procedures 5-9
4. Push down on the hard drive bezel on the front of the hard drive ➊ (Figure 5-8).
5. Lift the bezel up 90 degrees to create a handle ➋. Pull the hard drive out of the hard
drive bay.
Figure 5-8. Removing the Hard Drive
