Compat Ella - System Overview; Pump Components; Administration Set Overview; Button Functions

3. System Overview
3.1 Pump (see pages 3-4)
A
Pump door
B
Door latch
C
Pump rotor
D
Keypad
E
AC power status light
F
Colour display
G
Upstream pressure sensor
H
Downstream pressure sensor
I
Air sensor
J
Rubber foot pad
K
AC power connection
L
Pole clamp fitting
M
Rear pump label with Quick Start Guide
N
Loudspeaker
O
Serial number label
P
Legal manufacturer label
Q
AC power adapter
R
Pole clamp
3.2 Administration Set (see page 4)
S
ENPlus connector
U
ENFit
®
Medication port
T
Cassette
V
ENFit
®
Distal end
Note: Different versions of the administration sets are available. To obtain further information please contact your sales representative or go to
www.compat.com.
3.3 Button Function
The pump always retains in memory the on-screen settings and values when scrolling from one screen to the next, as well as when the pump is turned off.
Button Primary Function Secondary Function
Turn pump on or off (hold 2 seconds (2”))
Start / Pause pump Snooze alarm
Auto-prime (hold 2 seconds (2"))
Press again to stop auto-prime early
Scroll through rate, volume and interval programming
Switch between continuous and Interval modes
(hold 5 seconds (5”))
Decrease and increase values (hold: accelerates speed) Lock and unlock keypad (press both buttons together)
