The connection to the supervisor serial line, via the Modbus™, BACnet, or Lontalk protocols are
also supported via RS485 standard or over TCP/IP connection.
System 2500 is also equipped with USB peripheral that allowed easy firmware/software upgrade
via a standard thumb drive. Each controller supports both LCD and touch screen interface.
5.3 Mechanical Characteristics
SMALL 13 DIN modules 110 x 227.5 x 60mm
Plastic container
Assembly Fitted on DIN rail as per DIN 43880 and IEC EN 50022
Material techno-polymer
Flame redundancy V0 (UL94) and 960°C (IEC 695)
Ball pressure test 125°C
Resistance to creeping current ≥250 V
Color Grey RAL7035
5.4 Electrical Characteristics
Plug-in male/female connectors, max voltage 250 Vac;
cable cross-section: min. 0.5 mm2 - max 2.5 mm2
