 Trending
Each trending point is recorded and plotted for every 3 seconds. The following sensors are
supported.
 Room temperature
 Room humidity
 Discharge temperature
 Water in temperature
Figure 15. Trending plot
Trending history
Start a real time trending
Right scroll
Left scroll
Zoom in
Zoom out
Zoom full scale
Legend on/off
