Compu-aire SYSTEM 2500 - Page 9

Rev.01 03-27-17
Page 9 of 71
Compu-Aire
Compressor stage
 Active: Green
 OFF: Black
Heating stage
 Active: Red
 OFF: Black
Demand output
Pumpdown mode
Evaporator fan
Humidifier mode
Cooling mode
Dehumidification
mode
Heating mode
Econ/cooling assist
mode
Table 2 Icon legends
1
2
3
4
5
6
7
8
