NetPerformer SDM-8400 Hardware Installation Guide
3-4 Memotec
• Screw holes for the rackmount brackets have already been made at the factory
along the side of the unit chassis.
NOTE: Front mounting is also possible. To do this, install the rackmount bracket
to the left side of the SDM-8400 chassis when viewed from the front.
2. Screw the other rackmount bracket to the right side of the SDM-8400 chassis, using
2 small Phillips screws and 2 washers.
NOTE: The alternate location for front mounting is shown in Figure 3-1.
3. Carefully insert the SDM-8400 unit with the attached brackets into a standard 19"
equipment rack.
4. Secure the front of each bracket onto the rack using 2 mounting screws with cap locks
on each side.
