4.4 Console Port
4.4.1 Port
One PC-compatible console port:
• RJ-45 female connector
• TIA-232 (V.24) serial interface
• Autobaud asynchronous transmission, 1200, 2400, 4800, 9600, 19200, 28800,
38400, 57600 and 115200 bps
NOTE: The equipment you connect to the console port must operate at 9600 bps
when you first power up the SDM-8400 unit. Also, if you are connecting to
the console terminal via a modem, you must set the modem to ignore DTR.
See “Important Console and Modem Settings for Startup” on page 3-9.
• Autosensing gender, DTE/DCE
• Protocol: VT-100 or PPP
• Reverse console function also available for satellite applications (SkyPerformer).
4.4.2 Console Cable
A console cable kit for the console port is included with the SDM-8400 product package.
This kit includes:
• 1 14-ft. (4.25 m) standard TIA-232 (V.24) straight-through cable with RJ-45 male
connectors at both ends (Part no. 502-0808-014), and
• 1 TIA-232 (V.24) adaptor for console terminal connection, RJ-45 female to DB-9
female (Part no. 502-0635-001).
The console port (labelled
CSL) has an RJ-45 female connector to attach the factory-
supplied console cable. Use the RJ-45 to DB-9 adaptor to connect the console cable to the
workstation that will serve as the console terminal. Refer to “Connecting the Console
Terminal” on page 3-9.
RJ-45
Connector for
Console Port
The RJ-45 female connector marked CSL provides a physical port for attachment of the
console cable. It is a dedicated port with autosensing DTE/DCE mode and autobaud.
The following table describes the RJ-45 pinout for the console port.
Pin No. Usage Description
1 RTS Request To Send
Table 4-5: RJ-45 pinout for console port
