NetPerformer SDM-8400 Hardware Installation Guide
4-6 Memotec
The following table describes the RJ-45 pinout for the LAN port.
Pin No. Usage Description
1 TX+ Transmit (+) Output
2 TX- Transmit (-) Output
3 RX+ Receive (+) Input
4 – (not used)
5 – (not used)
6 RX- Receive (-) Input
7 – (not used)
8 – (not used)
Table 4-4: RJ-45 pinout for Ethernet LAN port
