Memotec 4-5
4.3 Ethernet Port
4.3.1 Port
• 1 fully routed Ethernet IEEE 802.3 LAN interface
• RJ-45 10/100BaseT connector
• Can be configured with 2 IP addresses
• Auto-detect speed, 10 or 100 Mbps
• Frame types: Ethernet II, IEEE 802.2, 802.3, SNAP
• Ethernet interface: Ethernet II and IEEE 802.2, 802.3
• Standards: IP RIP V1/V2 or Static, OSPF, NAT, IP Multicast IGMP V1/V2 PIM-
DM, BOOTP/DHCP Relay, DHCP client, IPX RIP and SAP, LLC2, 802.1p/q
prioritization and VLAN, 802.1D Spanning Tree Protocol (STP), MAC Layer
• Filter Criteria: Based on protocol, address (source, destination or SAP) or custom
filtering.
For information on connecting to the LAN hub, refer to “Connecting the LAN Hub” on
page 3-11.
4.3.2 LAN Port Status LEDs
Two LAN status indicators are located below the Ethernet port on the rear panel of the
SDM-8400 chassis (refer to
Table 4-1). These LEDs indicate the following:
•
LNK: Goes on when the LAN connection passes the Link Integrity test. In
addition, the LED color indicates the LAN speed:
- Amber: Link integrity at 100 Mbps
- Green: Link integrity at 10 Mbps
- Off: No link integrity signal detected.
•
ACT: Goes on (green) when there is activity on the LAN port (LAN traffic
transmitted or received).
4.3.3 LAN Cable
The Ethernet LAN port has an RJ-45 female connector to attach a LAN cable. Select a
standard LAN cable with RJ-45 connectors at both ends.
RJ-45
Connector for
Ethernet LAN
Port
The RJ-45 female connector marked ETH on the rear panel of the SDM-8400 provides a
physical LAN port for attachment to the local LAN hub (10/100Base-T, MDI connection).
