9
Loading the Batteries
The Concord Eye-Q Duo 2000 uses 2x AA LR6 batteries.
Loading the Batteries:
1. Locate the battery door on the bottom of the
camera.
2. Slide the button on the battery door towards the
center of the camera. (fig.1.1)
3. Lift the battery door to open.
4. Insert the batteries with the positive terminal
toward the + sign, and the negative terminal
toward the – sign. (fig.1.2)
5. Close the battery door.
Note: Remove the batteries from the Concord Eye-Q Duo 2000 if the
camera will not be used for an extended period of time to prevent
corrosion or battery leaks.
Checking the Batteries
The camera has a battery indicator that shows the current battery level.
FULL
Batteries are full
and ready to use.
LOW
Batteries are low
and need to be
replaced soon.
fig.1.1
fig.1.2
