4.0 TECHNICAL INFORMATION
4.1 Light Source
I.E.C. Equipment Classification: Type BF, Class 1, continuous operation
Typical Operating Requirements:
Input Voltage: 100 - 240 VAC
Input Line Frequency: 50/60Hz
Power Consumption: 500 VA max
Fuse: Fast Blow 6.3 Amps, 250 V
Intensity Control: Manual or Automatic
Weight: 16.0 lbs. (7.26 kg)
Dimensions: 14.0” (W) x 5.2” (H) x 15.1” (D)
35.5cm (W) x 13.2cm (H) x 38.4cm (D)
Power Cable Length: 6 ft. (2m)
ENVIRONMENTAL
Operating: Ambient Temperature: + 42° F to 86° F (+ 6° C to 30° C)
Relative Humidity: 30% to 85%
Atmospheric Pressure: 700 hPa to 1060 hPa
Transport and Storage: Ambient Temperature: -40° F to 120° F (-40° C to + 49° C)
Relative Humidity: 10% to 100%
Atmospheric Pressure: 500 hPa to 1060 hPa
4.2 Lamp Module
Lamp Type: Xenon Short Arc Lamp
Lamp Power: 300 Watts
Lamp Color Temperature: 5900°K
Lamp Life: 500 Hours Minimum
