Connect Tech Hadron Carrier - Connector Summary; Jumper and Switch Summary

Hadron/ Hadron DM Carrier
Users Guide
www.connecttech.com
Document: CTIM-00088
Revision: 0.08
Page 12 of 41
Date: 2024-05-15
Connector Summary
Designator
Connector
Description
P1
2309413-1
Module Board-To-Board Connector for:
• NVIDIA® Jetson Xavier™ NX
• NVIDIA® Jetson Orin™ NX
P2
98414-G06-10LF
GbE Connector
P3
TFM-110-02-L-D-WT
Dual Port USB 3.0 Connector
P4
TFM-120-02-L-D-WT
I/O Header
P5
10128797-004RLF
M.2 E-Key Connector
P6
10131758-001RLF
M.2 M-Key (NVMe) Connector
P7, P11 (NGX024 only)
54548-2271
4-lane MIPI CSI-2 Camera Connector
P8
98414-G06-06LF
Input Power Connector
P9
53047-0310
3-pin RTC Battery Connector
P10
53047-0410
5V Fan Connector
P13 (NGX024 only)
53047-0210
Power/ Wake Switch
P12 (NGX024 only)
53047-0210
Force Recovery/Reset Switch
Jumper and Switch Summary
Designator
Connector
Description
S1
1571983-1
Host Mode / Device Mode Selection Switch
J2
(NGX012 only)
HTSW-102-08-G-S
Force Recovery/Reset Jumper Block
