INTRODUCTION
Connect Tech’s Hadron platform brings a low cost deployable Jetson solution to the market. The
Hadron’s design includes 1x Gigabit Ethernet, 2 x USB 3.1 (when using NVIDIA® Jetson Orin™ NX), 1 x
MIPI CSI-2 (4 lane), 4x GPIOs (2x PWM capable), 3x UART, 1x I2C, 1x SPI.
Product Feature and Specifications
Feature
Description
Module Compatibility
NVIDIA® Jetson Xavier™ NX
NVIDIA® Jetson Orin™ NX
NVIDIA® Jetson Orin™ Nano
Mechanical Dimensions
82.65mm x 58.8mm (3.25" x 2.31")
USB
2x USB 3.1 Gen
• 1x USB 3.0 Host Only
• 1x USB 3.0 Dual Function – Host / Device mode
(Selectable by S1 switch)
Note – Dual Function port will be used when the system enters Force
Recovery Mode
MIPI Cameras
1x 4-lane MIPI CSI-2 (2-lane support available with 22-to-15 pin FFC/FPC
cable)
Connector P/N: 54548-2271
22-pin FPC 0.5mm Pitch Connector
Storage
1x M.2 M-Key (NVMe) expansion slot (4 lane PCIe Gen 4)
Support for 2242 and 2230 sized NVMe
IO – Ethernet
1x 10/100/1000BASE-T Uplink
IO – UART Debug
1x Debug UART (I/O header)
IO – UART
2x RS-232 (I/O header)
IO – I2C
1x I2C bus (I/O header)
IO – SPI
1x SPI bus (I/O header)
IO – GPIO / PWM
4x GPIO (I/O header) – 2x PWM Capable
User Expansion
1x M.2 Key-E Expansion Slot (1 lane PCIe Gen 3, USB 2.0)
For Wi-Fi/Bluetooth modules
RTC Battery
3-Pin RTC Battery Connector
Input Power
+9V to +60V DC Wide Input Power (6-pin Minitek Connector)
Operating Temperature
-25°C to +85°C (-13°F to +185°F)
Weight
49 grams
Warranty and Support
1 Year Warranty and Free Support
