THERMAL DETAILS
The Hadron/Hadron DM Carrier has an Operating Temperature Range of -25°C to +85°C.
However, it is important to note that the NVIDIA® Jetson Orin™ NX/ NVIDIA® Jetson Xavier™ NX Module
has its own properties separate to that of the Hadron/Hadron DM Carrier. The Hadron and Hadron DM
are rated for Operating Temperature Range of -25°C to +85°C.
Customer responsibility requires proper implementation of a thermal solution that maintains the
Hadron SoC and Thermal Transfer Plate (TTP) temperatures below the specified temperatures (shown in
the tables below) under the maximum thermal load and system conditions for their use case.
NVIDIA® Jetson Orin™ NX
Parameter
Value
Units
Maximum Orin™ NX SoC Operating Temperature
T.cpu = 99
°C
T.gpu = 99
°C
Orin™ NX SoC Shutdown Temperature
T.cpu = 105
°C
T.gpu = 105
°C
NVIDIA® Jetson Xavier™ NX
Parameter
Value
Units
Maximum Xavier™ SoC Operating Temperature
T.cpu = 90.5
°C
T.gpu = 91.5
°C
Xavier™ SoC Shutdown Temperature
T.cpu = 96.0
°C
T.gpu = 95.5
°C
CABLE INFORMATION
Drawing No.
Part No.
Function
Description
CTIC-00431
CBG112
(NGX012
0nly)
Power Cable
6-pin MiniTek w/ Latch, unterminated
CTIC-00883
CBG732
(NGX024
only)
Power Cable
Nano-Fit 2x2 to DC Jack Power Cable
CTIC-00433
CBG117
Ethernet Cable
10-pin MiniTek w/ Latch, RJ-45 Panel Mount
CTIC-00477
CBG136
RTC Battery Cable
Molex 3 Position 1.25mm PicoBlade Connector
N/A
CBG615
USB2.0 Cable
20-pin Tiger-Eye to 2x USB 2.0 Type-A Female
