Hadron/ Hadron DM Carrier
Users Guide
www.connecttech.com
Document: CTIM-00088
Revision: 0.08
Page 35 of 41
Date: 2024-05-15
N/A
CBG629
I/O cable
40-pin Tiger-Eye to Unterminated Flying Leads
N/A
CBG686
USB3.0 Cable
20-pin Tiger-Eye to 2x USB 3.0 Type-A Female (200mm)
N/A
XBG023
USB 3.0 Breakout
Board
20-pin Tiger-Eye to 2x USB 3.0 Type-A Female
Cable Components:
Below is the list of components required to assemble the USB and I/O cable for Hadron/Hadron DM
Carrier:
Component
USB Cable
I/O Cable
Connector Housing
ISDF-10-D-M
ISDF-20-D-M
Crimp Contact
CC03M-2830-GF
CC03M-2830-GF
Crimp Hand tool
CAT-HT-203-2830-12
CAT-HT-203-2830-12
Wire Gauge
28 – 30 AWG
28 – 30 AWG
Notes
USB Differential pairs needs to be
twisted pairs
3.3V and 5V output is limited to
500mA each.
