Connect Tech Hadron Carrier - Page 38

Hadron/ Hadron DM Carrier
Users Guide
www.connecttech.com
Document: CTIM-00088
Revision: 0.08
Page 38 of 41
Date: 2024-05-15
ANNEXURE I
NGX012 vs NGX024
Specification Differences
Feature
Details
NGX012
NGX024
Jetson Module
Compatibility
NVIDIA® Jetson Xavier™ NX
NVIDIA® Jetson Orin™ NX
NVIDIA® Jetson Xavier™ NX
NVIDIA® Jetson Orin™ NX
Ethernet
1x 1000BASE-T Ethernet Port
- 1x sourced from Native Jetson Port
- Connector: Amphenol Minitek 10 pin (PN:
98411-G06-10LF)
- Compatible Cable: CBG117
1x 1000BASE-T Ethernet Port
- 1x sourced from Native Jetson Port
- Connector: Amphenol Minitek 10 pin (PN:
98411-G06-10LF)
- Compatible Cable: CBG117
USB
2x USB 3.0 (one with OTG capability, the other
without)
- Connector: TFM 20-pin
2x USB 3.0 (one with OTG capability, the other
without)
- Connector: TFM 20-pin
Storage
1x M.2 M-Key 2230/2242 SSD Slot (PCIe x4)
1x M.2 M-Key 2230/2242 SSD Slot (PCIe x4)
Wireless Expansion
1x M.2 E-Key (2230 Sized)
- PCIe + USB 2.0 Sourced from NX
1x M.2 E-Key (2230 Sized)
- PCIe + USB 2.0 Sourced from NX
UART
1x 3.3V Logic Level UART (Debug Port)
- RX/TX/GND Only
2x RS232 Line Level
- TX, RX, RTS, CTS, GND
All three go to connector: Grouped IO TFM 40-pin
1x 3.3V Logic Level UART (Debug Port)
- RX/TX/GND Only
2x RS232 Line Level
- TX, RX, RTS, CTS, GND
All three go to connector: Grouped IO TFM 40-pin
I2C
1x 3.3V I2C Host Ports
- Connector: Grouped IO TFM 40-pin
1x 3.3V I2C Host Ports
Connector: Grouped IO TFM 40-pin
SPI
1x 3.3V SPI Host Ports
- Connector: Grouped IO TFM 40-pin
1x 3.3V SPI Host Ports
- Connector: Grouped IO TFM 40-pin
GPIO
4x 3.3V Logic GPIO Pins
- Sourced from module
- 1x GPIO will function as Output only (GTRI
power enable block)
- Connector: Grouped IO TFM 40-pin
4x 3.3V Logic GPIO Pins
- Sourced from module
- 1x GPIO will function as Output only (GTRI
power enable block)
- Connector: Grouped IO TFM 40-pin
Display Output
None (headless)
None (headless)
MIPI
1x 4-lane MIPI CSI-2
2x 4-lane MIPI CSI-2
FAN
1x FAN w/ PWM Control (5V operation)
- Connector: Picoblade
1x FAN w/ PWM Control (5V operation)
Connector: Picoblade
Input Power /
Misc Power Details
Single Input +9V to +60V (Nominal will be +15.8V)
- Connector: 6-pin Minitek Connector
- Cable: CBG112
- Auto-ON operation by default
Single Input +9V to +60V (Nominal will be +15.8V)
- Connector: 4-pin Molex Nano-Fit connector
- Cable: CBG706
- Auto-ON operation by default
- Power/Wake switch
Battery
3V RTC battery
- Connector: Picoblade 3-pin
3V RTC battery
- Connector: Picoblade 3-pin
Operating Temperature
-25°C to +85°C (Carrier board operating temp only)
-25°C to +85°C (Carrier board operating temp only)
PCB Thickness
2mm
2mm
PCBA Inspection and
Acceptance Criteria
IPC-A-610 Class 2
IPC-A-610 Class 2
Mechanical Details
82.65mm x 58.80mm
82.65mm x 58.80mm
Environmental
Requirements
Ingress Protection: N/A
EMC/EMI: N/A
Shock/Vibration: N/A
Test Not Required by Connect Tech
Ingress Protection: N/A
EMC/EMI: N/A
Shock/Vibration: N/A
Test Not Required by Connect Tech
Warranty and Support
1 Year Warranty and Free Support
1 Year Warranty and Free Support
