Connector Summary
Designator
Connector
Description
P1
TX2/TX2i Module Connector
NVIDIA Jetson TX2/TX2i/TX1 Module Board-to-Board
Connector
P2
HDMI
HDMI 2.0 Maximum: 6Gbps, 24bpp, 4096x2160@60Hz
P4
Expansion IO Header
Expansion IO Header Interfacing to all Misc IO
P5
Gigabit Ethernet
Gigabit Ethernet 10/100/1000 BASE-T Connection
P6
Micro SD Card Slot
Micro SD Card Slot (4-bit Data, Support for SD 4.0)
P7
USB 3.0
USB 3.0 Type-A Host Connection
P8
USB OTG
USB OTG (Host Mode and Client Mode capable)
P9
Power Input
DC Power Input (+9V to +14V)
Switch Summary & Locations
Designator
Function
Description
S1
Fan / Power Control
Power Start-up Control, FAN PWM / Always ON Control
SW1
Power Button
Power Button, Press to Power ON or OFF
SW2
Reset Button
Reset Button, Press to initiate Reset Sequence
SW3
Recovery
Use to initiate a recovery mode, and flash new image via USB OTG
