ORBITTYBOX ENCLOSURE – ENC001
Connect Tech’s OrbittyBox easily turns the Orbitty carrier into a complete packaged NVIDIA® Jetson™
TX2 system. This two-piece metal enclosure is designed to house an Orbitty Carrier, NVIDIA® Jetson™
TX2 module, and Connect Tech’s active heat sink. The enclosure is sold as an accessory, allowing it to be
integrated with existing customer product. Two-piece construction for ease of installation and assembly.
Specifications
Feature OrbittyBox
Compatibility
NVIDIA Jetson TX2
Enclosure 2-Piece Metal Enclosure
Dimensions
95.3mm x 63mm x 58.3mm (3.75” x 2.48” x 2.30”) (WxHxD)
Weight
Enclosure + Fasteners – 113g (0.25lb)
(Orbitty, Module, Heat Sink – 204g [0.45lb])
Antenna Optional 2x SMA Antenna Connectors
