Connect Tech NVIDIA Jetson TX2 - Internal Heights Drawing; Related Part Numbers

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 31 of 31 Date: 2021-10-05
Internal Heights Drawing
Related Part Numbers
Product Name Part Number
OrbittyBox
ENC001
Orbitty Carrier Board
ASG003
NVIDIA® Jetson™ TX2
CMG503-21
Active Heat Sink
XHG302
Passive Heat Sink
XHG301
SMA Cable – Female, U.FL
CBG225
MSG066
Dual Band Antenna
* All products sold separately
