MECHANICAL DRAWINGS & MODELS
3D STEP Model
A complete 3D STEP Model file of the Orbitty Carrier can be downloaded here:
https://www.connecttech.com/ftp/3d_models/ASG003_3D_MODEL.zip
2D Dimensions Drawing
