8. STANDARD ADJUSTMENTS
8-13. Adjusting the feed regulator
If the stitch length of forward and reverse are not
same,make adjustment of feed regulator.
1. Remove the arm rear cover plate •.
2. Turn the cover plate
f) ,loosen the screw ewith
holding upward the reverse lever.
3. When the mark of feed regulator
0 and feed
regulator rod
0 are alignment, stitch length of
forward and reverse will be same.
4. Turn feed regulator rod
0to the arrow "X", stitch
length of reverse is bigger and stitch length of
forward is smoller.
5. Turn feed regulator rod
0to the arrow "Y" ,stitch
length of reverse is smoller and stitch length of
forward is bigger.
6. After adjustment,tigthen the screw
e.
