EMS-96 Instruction Manual IM1200-U v1.6 Pag. 11 / 48
2 analog outputs (option)
With this option the instrument will be equipped with:
- 2 pulse / state digital outputs
- 2 analog outputs.
2 analog outputs, 2 digital outputs (option)
With this option the instrument will be equipped with:
- 4 pulse / state digital outputs
- 2 analog outputs.
4 analog outputs (option)
With this option the instrument will be equipped with:
- 2 pulse / state digital outputs
- 4 analog outputs.
4 analog outputs, 2 digital outputs (option)
With this option the instrument will be equipped with:
- 4 pulse / state digital outputs
- 4 analog outputs.
Ao1-
Ao1+
Ao2-
Ao2+
Do1-
Do1+
Do2-
Do2+
Ao1-
Ao1+
Ao2-
Ao2+
Do3-
Do3+
Do4-
Do4+
Do1-
Do1+
Do2-
Do2+
Ao1-
Ao1+
Ao2-
Ao2+
Ao3-
Ao3+
Ao4-
Ao4+
Do1-
Do1+
Do2-
Do2+
Ao1-
Ao1+
Ao2-
Ao2+
Ao3-
Ao3+
Ao4-
Ao4+
Do3-
Do3+
Do4-
Do4+
Do1-
Do1+
Do2-
Do2+
Digital Inputs/Outputs
Ao1- Ao2- Ao3-
Ao4+
Ao1+ Ao2+
Ao3+
Ao4-
Voltage analog outputs
EMS
Di1- Di2-
Do2-
Do1+
Di1+ Di2+
Do2+
Do1-
24, 48,
115, 230 Vaa/dc
depending by the version
fuse
V
fuse
150mA max 150mA max
12÷230
Vac/dc
12÷230
Vac/dc
V VV
EMS
V
out
Load
V
out
Min 1K Min 1K
Current analog outputs
I
out
I
out
Max 600 Max 600
Analog Outputs
LoadLoadLoadLoad
Load
