Acronym tables
Acronyms group table
Acronym
Instantaneous
Average
Energies
Setpoint
Acronyms table of Instantaneous group
Acronym
Explanation
Acronym
Explanation
Acronym
Explanation
V
System Voltage
VA
System Apparent Power
THD A2
THD Current L2
V1
Voltage L1
VA1
Apparent Power L1
THD A3
THD Current L3
V2
Voltage L2
VA2
Apparent Power L2
DEG V1-V2
Phase Angle L1-L2
V3
Voltage L3
VA3
Apparent Power L3
DEG V2-V3
Phase Angle L2-L3
V1-V2
L1-L2 Voltage
W
System Active Power
DEG V3-V1
Phase Angle L3-L1
V2-V3
L2-L3 Voltage
W1
Active Power L1
TAN
System Tan
V3-V1
L3-L1 Voltage
W2
Active Power L2
TAN1
Tan L1
A
System Current
W3
Active Power L3
TAN2
Tan L2
A1
Current L1
VAr
System Reactive Power
TAN3
Tan L3
A2
Current L2
VAr1
Reactive Power L1
EXP W
System Expected Power
A3
Current L3
VAr2
Reactive Power L2
EXP W1
Expected Power L1
PF
System Power Factor
VAr3
Reactive Power L3
EXP W2
Expected Power L2
PF1
Power Factor L1
4° A
4
th
Current Input
EXP W3
Expected Power L3
PF2
Power Factor L2
FREQ
Frequency
DEG V-A 1
Phase Angle V1-A1
PF3
Power Factor L3
INT TEMP
internal temperature
DEG V-A 2
Phase Angle V2-A2
COS
System COS
THD V1
THD Voltage L1
DEG V-A 3
Phase Angle V3-A3
COS1
COS L1
THD V2
THD Voltage L2
k
Insulation
COS2
COS L2
THD V3
THD Voltage L3
PT-100
Ext. temperature from PT-100
COS3
COS L3
THD A1
THD Current L1
Acronyms table of Average group
Acronym
Explanation
Acronym
Explanation
Acronym
Explanation
AVG V
System Average Voltage
AVG COS
Average COS L1
AVG VAr
System Average Reactive Power
AVG V1
Average Voltage Phase 1
AVG COS1
Average COS L2
AVG VAr1
Average Reactive Power L1
AVG V2
Average Voltage Phase 2
AVG COS2
Average COS L3
AVG VAr2
Average Reactive Power L2
AVG V3
Average Voltage Phase 3
AVG-COS3
System Average Apparent Power
AVG VAr3
Average Reactive Power L3
AVG A
System Average Current
AVG VA
Average Apparent Power L1
AVG 4° A
4
th
Current Input
AVG A1
Average Current L1
AVG VA1
Average Apparent Power L2
AVG Hz
Average Frequency
AVG A2
Average Current L2
AVG VA2
Average Apparent Power L3
AVG TAN
Average System Tan
AVG A3
Average Current L3
AVG VA3
System Average Active Power
AVG TAN1
Average Tan L1
AVG PF
System Average Power Factor
AVG W
Average Active Power L1
AVG TAN2
Average Tan L2
AVG PF1
Average Power Factor L1
AVG W1
Average Active Power L2
AVG TAN3
Average Tan L3
AVG PF2
Average Power Factor L2
AVG W2
Average Active Power L3
AVG PF3
Average Power Factor L3
AVG W3
Average COS L1
Acronyms table of Energies and TB (from 1 to 16) groups
Acronym
Explanation
Acronym
Explanation
Acronym
Explanation
Wh IN
System Active Energy IN
VArh IN 1
Reactive Energy L1 IN
VAh 2
Apparent Energy L2
Wh OUT
System Active Energy OUT
VArh OUT 1
Reactive Energy L1 OUT
Wh IN 3
Active Energy L3 IN
VArh IN
System Reactive Energy IN
VAh 1
Apparent Energy L1
Wh OUT 3
Active Energy L3 OUT
VArh OUT
System Reactive Energy OUT
Wh IN 2
Active Energy L2 IN
VArh IN 3
Reactive Energy L3 IN
VAh
System Apparent Energy
Wh OUT 2
Active Energy L2 OUT
VArh OUT 3
Reactive Energy L3 OUT
Wh IN 1
Active Energy L1 IN
VArh IN 2
Reactive Energy L2 IN
VAh 3
Apparent Energy L3
Wh OUT 1
Active Energy L1 OUT
VArh OUT 2
Reactive Energy L2 OUT
