EMS-96 Instruction Manual IM1200-U v1.6 Pag. 30 / 48
Energies and Counters
The EMS-96 has 4, 8 or 16 timebands (depending of the option) to differentiate the power consumption. You can schedule the
exchange of the timebands using manual (Modbus command), from DI (digital inputs) or Preset (Setup  Timeband  Mode  Preset).
With from DI it’s necessary to set the use of digital inputs for this purpose (Setup  I/O  DI 1, 2, 3, 4  Mode  Change TB).
With Preset it is necessary to define a Daily plan in which you set the time of transition (maximum 16) from one to the next
timeband. In the setting of Period plan (Setup  Timeband  Preset  Daily/Period Plan) it will be selected the month and the day
of the start and the end, and it will be necessary to link each Daily Plan to one or more days of the week. At the end of settings
the Period Plan will be enabled. Any holidays will be set in the menu Holidays (Settings  Timeband  Preset  Holidays).
Setup  Measure  Energies/Counters  Mode
Mode Timeband (option)
Range
Default
Energy changing
manual / from DI / preset
manual
It’s possible to select the modality to change the timeband:
- Manual.
- From DI: the combination of digital inputs select the actual timeband (TB) used (see the following table).
- Preset (see timeband Daily and Period plan for more information).
Counter changing
manual / from DI
manual
It’s possible to select the modality for change the timeband:
- Manual.
- From DI: the combination of digital input select the actual timeband (TB) used (see the following table).
DI4
DI3
DI2
DI1
TB used
DI4
DI3
DI2
DI1
TB used
DI4
DI3
DI2
DI1
TB used
DI4
DI3
DI2
DI1
TB used
0
0
0
0
1
0
1
0
0
5
1
0
0
0
9
1
1
0
0
13
0
0
0
1
2
0
1
0
1
6
1
0
0
1
10
1
1
0
1
14
0
0
1
0
3
0
1
1
0
7
1
0
1
0
11
1
1
1
0
15
0
0
1
1
4
0
1
1
1
8
1
0
1
1
12
1
1
1
1
16
Setup  Measure  Energies/Counters  Daily plan
Daily Plan X (from 1 to 16) (option)
Range
Default
Start Hour 1
00 ÷ 23
0
Hour at which the timeband will be changed.
Start Minute 1
00 ÷ 59
0
Minute at which the timeband will be changed.
Timeband Used 1
not used ÷ TB-XX* (band)
not used
New Timeband set.
………………..
………………..
Start Hour 16
00 ÷ 23
0
Hour at which the timeband will be changed.
Start Minute 16
00 ÷ 59
0
Minute at which the timeband will be changed.
Timeband Used 16
not used ÷ TB-XX* (band)
not used
New Timeband set.
* XX in TB-XX, depends from the number of the Timeband enabled.
Setup  Measure  Energies/Counters  Period plan
Period Plan X (from 1 to 16) (option)
Range
Default
Enable
yes / no
no
Enable or disable the plan. WARNING: Set all the following parameters before to enable it.
Start Month
January ÷ December
January
Month at which the period start.
Start Day
1 ÷ 31
1
Day at which the period start.
End Month
January ÷ December
December
Month at which the period finish.
End Day
1 ÷ 31
31
Day at which the period finish.
Monday Plan
Plan 1 ÷ Plan 16
Plan 1
Plan used for this day.
………………..
………………..
Sunday Plan
Plan 1 ÷ Plan 16
Plan 1
Plan used for this day.
