EMS-96 Instruction Manual IM1200-U v1.6 Pag. 41 / 48
Log
The EMS-96 can sample up to 15 measures with 4 different log types.
Warning: only at the end of the Log settings you can proceed to the enabling (see examples).
Generic
It’s possible to sample with frequency from 1 second to once a month between instantaneous measurements, medium and
energies.
Setup  Log  Generic
Generic Log (option)
Range
Default
Enable
yes / no
no
Enable or disable the generic log. Before to enable the log functionality, it’s necessary to disable any other activated log.
It is possible to use only one type of log at a time.
Sampling
1sec / 2sec / 3sec / 5sec / 6sec / 10sec / 12sec / 15sec / 20sec / 30
sec / 1min / 2min / 3min / 5min / 6min / 10min / 12min / 15min / 20
min / 30min / 60min / end of day / end of week / end of month
15 min
Acquisition timing.
Storage Type
FIFO / end memory
end memory
Type of storage. Note: FIFO after 10 consecutive cycles is automatically disabled.
Group 1
See Acronym Group table
---
Selection of the group for the 1
st
measure sampled for the generic log.
Measure 1
See acronym in the table of the group selected
---
Selection of the 1
st
measure sampled for the generic log.
………………..
………………..
Group 15
See Acronym Group table
---
Selection of the group for the 15
st
measure sampled for the generic log.
Measure 15
See acronym in the table of the group selected
---
Selection of the 15
st
measure sampled for the generic log.
Warning: All recordings for all log will be lost if any parameter is changed.
Example: Setup  Log  Generic Sampling 20 sec
Storage type end memory
Group 1 instant
Measure 1 W1
Group 2 instant
Measure 2 W2
Group 3 instant
Measure 3 W3
Group 4 instant
Measure 4 COS1
Group 5 instant
Measure 5 COS2
Group 6 instant
Measure 6 COS3
Enable yes
To display how many log were acquired and the remaining storing time:
Information  Log summary  Generic.
To display the single log:
Information  Log detail  Generic.
