EMS-96 Instruction Manual IM1200-U v1.6 Pag. 33 / 48
Setup  User pages  Titles
Edit title
Range
Default
User page 1
---
VOLTAGES
Title displayed in the User Page.
User page 2
---
PHASE PHASE
Title displayed in the User Page.
User page 3
---
CURRENTS
Title displayed in the User Page.
User page 4
---
POWER FACTOR
Title displayed in the User Page.
User page 5
---
ACTIVE POWER
Title displayed in the User Page.
User page 6
---
REACTIVE POWER
Title displayed in the User Page.
Setup  User pages  Keys Text
Edit keys texts
Range
Default
Key 1
---
L-N
Text associated with the function of the key.
Key 2
---
L-L
Text associated with the function of the key.
Key 3
---
A
Text associated with the function of the key.
Key 4
---
P.F.
Text associated with the function of the key.
Key 5
---
W
Text associated with the function of the key.
Key 6
---
VAr
Text associated with the function of the key.
Example: Setup  User pages  Titles User page 1 Warehouse
Setup  User pages  Type User page 1 instant
Setup  User pages  Composition Row 1 W1
Setup  User pages  Composition Row 2 VAr1
Setup  User pages  Composition Row 3 W2
Setup  User pages  Composition Row 4 VAr2
Setup  User pages  Composition Row 5 W3
Setup  User pages  Composition Row 6 VAr3
With these set the user page will be this:
Warehouse
W1
X.XXX kW
VAr1
X.XXX kVAr
W2
X.XXX kW
VAr2
X.XXX kVAr
W3
X.XXX kW
VAr3
X.XXX kVAr
