EMS-96 Instruction Manual IM1200-U v1.6 Pag. 35 / 48
Setup  Communication  Ethernet
Ethernet (option)
Range
Default
Address [node]
1 ÷ 247
1
Identification instrument in the Modbus network.
IP address
0.0.0.0 ÷ 255.255.255.255
10.0.0.100
IP address associated to the instrument.
Subnet mask
0.0.0.0 ÷ 255.255.255.255
255.0.0.0
Subnet mask associated to the instrument.
IP gateway
0.0.0.0 ÷ 255.255.255.255
10.0.0.254
IP address of the gateway associated to the instrument.
IP Port
0 ÷ 65535
502
Number of the TCP port for the Modbus communication.
IP Wifi
0.0.0.0 ÷ 255.255.255.255
1.0.0.1
IP Wifi address associated to the instrument.
Setup  Communication  M-Bus
M-Bus (option)
Range
Default
Address [node]
0 ÷ 250
1
Instrument identifier on the M-BUS network.
Baud rate [kbit/s]
300 / 600 / 1200 / 2400 / 4800 / 9600 / 19200 / 38400
2400
Communication speed.
Stop bits
1 / 2 stop bits
1 stop
Communication parameters.
Parity
None / Odd / Even
Even
Communication parameters.
Min Response delay [ms]
0 ÷100
10
If set 0 the instrument responds as soon as possible.
Setup  Communication  M-Bus  Readout data
M-Bus Readout Data (option)
Range
Default (*)
Group 1
See Acronym Group table
Instantaneous
Group of the 1
st
measure read.
Measure 1
See acronym in the table of the group selected
V
1
st
measure read.
………………..
………………..
Group 20
See Acronym Group table
Energies
Group of the 20
st
measure read.
Measure 20
See acronym in the table of the group selected
VArh OUT
20
th
measure read.
(*) Default Table Group / Measure of M-BUS Readout Data
Number of Group and Measure
Group
Measure
Number of Group and Measure
Group
Measure
1
Instantaneous
V
11
Instantaneous
PF2
2
Instantaneous
V1
12
Instantaneous
PF3
3
Instantaneous
V2
13
Instantaneous
W
4
Instantaneous
V3
14
Instantaneous
VAR
5
Instantaneous
A
15
Instantaneous
N
6
Instantaneous
A1
16
Instantaneous
Hz
7
Instantaneous
A2
17
Energies
Wh IN
8
Instantaneous
A3
18
Energies
Wh OUT
9
Instantaneous
PF
19
Energies
VArh IN
10
Instantaneous
PF1
20
Energies
VArh OUT
