Table 3.3 Commander SE Size 2, 200V dual rated units
* See section 3.1.1.
** For an explanation of inrush current, see section 3.1.2.
Table 3.4 Recommended supply fuses and cables
Table 3.5 Braking resistors
Before fitting a braking resistor please read the information on Braking, and
the Warnings on High Temperatures and Overload Protection at the end of
this section.
MODEL SE2D200...
075 110 150 220
AC supply voltage and frequency Single or 3 phase 200 to 240V +/- 10%, 48 to 62Hz
Input displacement factor (cos φ)>0.97
Nominal motor power - kW 0.75 1.1 1.5 2.2
Nominal motor power - HP 1.0
2.0 3.0
Output voltage and frequency 3 phase, 0 to input voltage, 0 to 1000Hz
100% RMS output current - A 4.3 5.8 7.5 10.0
150% overload current for 60 secs - A 6.5 8.7 11.3 15.9
Typical full load input current - A* 1ph/3ph 11.0 5.5 15.1 7.9 19.3 9.6 26.2 13.1
Typical inrush current - A**(duration <10ms) 55 35
Drive power losses at 230VAC at 6kHz switching
frequency - W 54 69 88 125
Weight - kg/lb 2.75 / 6
Cooling fan fitted No Yes
MODEL SE2D200...
075
110 150 220
1ph3ph1ph3ph1ph3ph1ph3ph
Recommended input supply fuse - A 16 10 20 16 25 16 32 20
Control cable mm² ≥ 0.5
AWG 20
Recommended input cable mm² 1.5 1.0 2.5 1.5 2.5 1.5 4.0 2.5
AWG1416121412141012
Recommended motor cable mm² 1.0 1.5
AWG 16 14
Recommended braking resistor cable mm² 1.0 1.5
AWG 16 14
MODEL SE2D200...
075 110 150 220
Minimum braking resistor value - Ω 50 40
Recommended braking resistor value - Ω 100 75 50
Maximum braking current - A 9 11
Resistor peak power rating - kW 1.8 2.4 3.5
NOTE
