Commander SE User Guide
14 Issue Number 5
3.3 RFI Filters
RFI filters are available as optional extra parts where required.
For compliance with EN61800-3 in the second environment, no filter is
required.
Humidity: Maximum relative humidity 95% (non-condensing)
Materials: Flammability rating of main enclosure:UL94-5VA
Grommets: UL94-V1
Vibration (random):
Vibration (sinusoidal)
Unpackaged - tested to 0.01g²/Hz (equivalent to 1.2g
rms)from5to150Hzfor1hourineachof3axesin
accordance with IEC68-2-34 and IEC68-2-36.
Unpackaged - tested from 2-9Hz, 3.5mm displacement;
9-200Hz 10m/s
2
acceleration; 200-500Hz, 15m/s
2
acceleration. Duration - 15 minutes in each of 3 axes.
Sweep rate 1 octave/minute.
Test in accordance with IEC68-2-6.
Bump: Packaged - tested to 40g, 6ms, 100 times/direction for
all 6 directions as in IEC68-2-29
Unpackaged - tested to 25g, 6ms, 100 times/direction
for all 6 directions in accordance with IEC68-2-29
Frequency accuracy: 0.01%
Resolution: 0.1Hz
Output frequency
range:
0to1000Hz
Starts per hour: By using the electronic control terminals: Unlimited
By switching of the supply: 20 starts per hour maximum
(3 minute intervals between starts)
Power up delay: 1 second maximum (Allow at least 1 second before
monitoring the state of the status relay contacts,
communicating with the Drive via serial
communications etc.)
Serial
Communications:
ANSI 2-wire EIA485 protocol via RJ45 connector
Switching
Frequencies:
3, 6, and 12 kHz are available with Intelligent Thermal
Management software automatically changing the
switching frequencies depending on load conditions,
heatsink temperature and output frequency, to prevent
heatsink overtemperature trips.
EMC: EN50082-2 and EN61800-3 for immunity
EN61800-3 second environment, without RFI filter
EN50081-1*, EN50081-2 and EN61800-3 first
environment, with optional RFI filter. See sections 3.3
and 4.5.
* Size 1 units only.
